| 發動機Engine |
| 型號Model | Yunnei 4108 |
| 額定功率Roted power | 92kw |
| 形式 Type | 四沖程，柴油Four stroke,diesel engine |
| 冷卻方式Cooling type | 水冷 |
| PERFORMANCE |
| zui大舉升能力 Max.lifting capacity | 4000kg |
| zui大舉升高度載重（zui大伸長）Capacity at max boom extension | 1800kg |
| zui大舉升高度：Max lifting height | 18000mm |
| zui大爬坡度Gradeablity | 30% |
| 自重 machine weight | 12000kg |
| zui高速度;Max Speed | 30km/h |
| 橋Axle |
| 驅動方式 Driving model | 四輪轉向4WS；蟹形轉向 Crab steering；前輪轉向:2WS |
| 前橋Front axle | 鋼體橋 Rigid |
| 后橋 Rear axle | 搖擺橋 Oscillating |
| 行車制動 Moving Brake | 四輪氣剎Servise air brake on the 4 wheels with double hydraulic system |
| 駐車制動 Parking Brake | 液壓Negative parking brake |
| 輪胎 Tires | 17.5-25 |
| DIMENTIONS |
| 長度 Length | 6800mm |
| 高度 Height | 2500mm |
| 寬度 Width | 2300mm |
| 軸距 Shaft distance | 3000mm |
